Old Man Emu BP51 Complete Toyota Tacoma Suspension Lift Kit (2005-2015)

The BP-51 system is more than a suspension upgrade—it’s a complete ride transformation. Whether you’re carving bad washboard roads, exploring remote trails, or towing and hauling, BP-51 shocks allow you to fine-tune damping for the perfect ride quality in any setup.

The front coilovers have been tuned in both length and feel specifically to the Tacoma and are capable of accommodating setups with and without accessories (bumpers, winch, etc). Specific reservoir brackets have been designed for application-specific reservoir placement and also relocation of the sway bar to allow clearance at the spring seat. While the front coilovers are adjustable in height, the system has been designed for a 2-inch (50mm) ride height increase and a minimum of 2-inch (50 mm) down travel.

Currently available for purchase, rear shock absorbers have been tuned in length and valving specific to the Tacoma. To accommodate the large body size of BP-51 a specific lower mount bracket has been developed to provide clearance to the axle. Specific reservoir brackets have also been developed and are included in the rear fit kit.

The rear dampers are tuned to match the existing range of rear Old Man Emu springs. Recommended compression and rebound settings can be found in the supplied fitting instructions for the various spring options available.

The fitting instructions include detailed information for the correct installation of the shock absorber and reservoir placement. Please note there is a left-hand and right-hand applications due to the different reservoir mounting methods and locations.

Key Features:

• 2–3” Suspension Lift – Improves ground clearance and tire fitment.
• BP-51 Adjustable Bypass Shocks – Internal bypass technology with fully adjustable compression and rebound tuning for ultimate control.
• Vehicle-Specific Engineering – Shocks, springs, and components designed around the Tacoma’s chassis and load ratings.
• Premium Ride Comfort – Smooths out rough terrain while keeping highway handling sharp.
• Load-Carrying Options – Multiple coil and leaf spring choices tailored for stock trucks or those equipped with armor, bumpers, campers, or overlanding gear.
• Built Tough – Precision-machined aluminum shock bodies resist corrosion and dissipate heat for long-lasting performance.

Kit includes:

• (1) BP5190006L Tacoma Front Left Coilover
• (1) BP5190006R Tacoma Front Right Coilover
• (1) VM80010016 – BP51 Fit Kit – Front
• (2) EL095R Leaf Springs
• (1) BP5160011L – Tacoma Left Rear Shock
• (1) BP5160011R – Tacoma Right Rear Shock
• (1) VM80010017 – Tacoma BP51 Fit Kit – Rear
• (1) FK29 – Driveshaft Fit Kit
• (4) U53A – Ubolts
• (2) SB108 – Spring Bushing Kit
• (2) 216522 – Sticker
• (1) 217195 – Water Bottle

Why Upgrade to BP-51?

Standard Nitrocharger kits deliver excellent value and comfort, but BP-51 takes it to the next level with adjustable shock tuning. This means you can dial in your suspension for daily drivability, then adjust on-trail for rough conditions or heavy loads. It’s the ultimate setup for serious Tacoma owners who demand performance without compromise.

Perfect for:

• Overlanding builds with variable gear loads
• Expedition rigs with campers, armor, or trailers
• Drivers who want the best possible ride quality both on and off-road

**NOTE: There is a left-hand and right-hand applications due to the different reservoir mounting methods and locations.
